Josam  /  Products
Product Image

46800 Series

46800 SERIES STAINLESS STEEL TRENCH DRAIN 16" WIDE WITH SS GRATING.

Specification
Josam series 46800 fabricated stainless steel (type 304, 2mm THK), 16" wide, v-shaped bottom, available with or without slope (1% STD), with anchor tabs and leveling feet, bottom outlet and grate options. Run lengths longer than 13' provided with flangesand gaskets.

Application

Product Details
Parts
List
Submittal Sheets
CAD Drawings
Resource Center
Price
Item
Domestic Content Message
OPTIONS
-BWButt-Weld Outlet (avail 10,40,80) -TThreaded Outlet
-FBFilter Basket -VPSecured Grate
-FCAnchor Flange and Clamp -316Type 316L Material
-SBSediment Bucket TD.LENGTHTotal Run Length
TYPE # GRATE TYPE
46812 REINFORCED
46813 "
46814 "
46816 "
46818 "
46822 ANTI-SLIP MESH
46823 "
46824 "
46826 "
46828 "
46832 SOLID/PERIMETER
46833 "
46834 "
46836 "
46838 "
46842 LADDER
46843 "
46844 "
46846 "
46848 "

Cross Reference Guides

This cross reference guide offers the best cross reference from other drain manufacturer’s products to a Josam equivalent series. You may need to add options to the Josam series to match the other manufacturer’s options. In some cases, adding options on a competitor’s model will require a different Josam series than the one selected in this chart. If you need assistance with product cross reference, please contact  Josam Customer Service.

JR Smith

Mifab

Wade

Watts

Zurn
